2MP 68x Long Range Zoom Network le Digital Dual Output Camera Module


> 1/1.8” Sony Exmor CMOS Sensor.
> Matlafatsa a matla a 68x (6~408mm).
> Max.2Mp(1920x1080) Qeto
> Ts'ehetsa mesebetsi e fapaneng ea IVS
> Tšehetsa Optical Defog
> Ts'ehetsa tlhahisoleseling e fapaneng ea OSD mabapi le marang-rang.
> Tšehetsa tlhahiso ea video ea dijithale ea LVDS ka tumellano.


Tlhaloso

Boemo

Mohlala

SG-ZCM2068ND-O

Sensoro

Sensor sa setšoantšo 1/1.8 ″ Sony Starvis e tsoelang pele ea scan ea CMOS
Lipikselse tse Sebetsang Hoo e ka bang.4.17 megapixels

Lense

Bolelele ba Tsepamiso 6mm ~ 408mm, 68x Optical Zoom
Sekoti F1.4~F4.6
Sebaka sa Pono H: 66.0°~1.0°, V: 40.3°~0.6°, D:73,4°~1.2°
Koala Bohole ba Tsepamiso 1m~5m (Wide~Tele)
Atometsa Lebelo Hoo e ka bang.8s (Optical Wide~Tele)
DORI Distance(Motho) Lemoha Ela hloko Lemoha Tseba
4,400m 1,746m 880m 440m

Video

Khatello H.265/H.264/H.264H/MJPEG
Bokhoni ba ho phallela 3 melapo
Qeto 50Hz: 25fps@2MP(1920×1080), 25fps@1MP(1280×720)60Hz: 30fps@2MP(1920×1080), 30fps@1MP(1280×720)
Video Bit Rate 32kbps~16Mbps
Audio AAC / MP2L2
Video ea LVDS 50Hz: 25fps@2MP(1920×1080)60Hz: 30fps@2MP(1920×1080)

Marang-rang

Polokelo Karete ea TF (256 GB), FTP, NAS
Network Protocol Onvif, HTTP, HTTPS, IPv4, IPv6, RTSP, DDNS, RTP, TCP, UDP
Multicast Tšehetso
Ntlafatso ea Firmware (LVDS) Ke feela e ka ntlafatsang firmware ka Network port.
Liketsahalo tse Akaretsang Motion, Tamper, SD Card, Network
IVS Tripwire, Thibelo ea Lekhoakhoa la Sefapano, Ho Kena, Ntho e Lahliloeng, E Tsamaeang ka Potlako, Pono ea Lipalangoang, Khakanyo ea Pokello ea Bongata, Ntho e Sieo, Ho Tseba ho Loitering.
Karolelano ea S/N ≥55dB (AGC Off, Weight ON)
Bonyane Bonyane Mmala: 0.005Lux/F1.4;B/W: 0.0005Lux/F1.4
Phokotso ea Lerata 2D/3D
Boemo ba Exposure Auto, Aperture Priority, Shutter Priority, Fumana Pele, Bukana
Hlahisa Puseletso Tšehetso
Lebelo la Shutter 1/1 ~ 1/30000s
BLC Tšehetso
HLC Tšehetso
WDR Tšehetso
White Balance Auto, Manual, Indoor, Outdoor, ATW, Sodium lamp, Street lamp, Natural, One Push
Motšehare/Bosiu Motlakase, ICR(Auto/Manual)
Mokhoa oa ho tsepamisa maikutlo Auto, Manual, Semi Auto, Fast Auto, Fast Semi Auto, One Push AF
Defog ea elektroniki Tšehetso
Defog ea Optical Tšehetso, mocha oa 750nm ~ 1100nm ke Optical Defog
Phokotso ea Mofuthu oa Mocheso Tšehetso
Fenya Tšehetso
EIS Tšehetso
Digital Zoom 16x
Taolo ea Kantle TTL
Sehokedi 4pin Ethernet port, 6pin Power & UART port, 5pin Audio port.30pin LVDS
Puisano Protocol SONY VISCA, Pleco D/P
Maemo a Tshebetso (-30°C~+60°C/20% ho isa ho 80%RH)
Maemo a polokelo (-40°C~+70°C/20% ho isa ho 95%RH
Phepelo ea motlakase DC 12V
Tšebeliso ea Matla Matla a tsitsitseng: 5W, Matla a lipapali: 6W
Litekanyo(L*W*H) 176mm*72mm*77mm
Boima ba 'mele 900g
